PVC Truck Tarpaulin

About PVC Truck Tarpaulin

18X36 SIZE

PVC Coated Fabric Technical Specification

1. Base Fabric

• Material: 100% Polyester (or other base fabrics such as nylon or fiberglass)

• Weave: Plain or Oxford

• Yarn Denier: 1000D, 500D, or as required

• Weight: 250900 gsm (grams per square meter)

• Tensile Strength: Minimum 2000 N/5cm (warp) and 1800 N/5cm (weft)

• Tear Strength: Minimum 250 N (warp/weft)

2. Coating

• Type: Polyvinyl Chloride (PVC)

• Coating Method: Knife coating, spread coating, or calendering

• Coating Thickness: 0.25 mm 1.0 mm depending on application

• Coating Weight: Typically contributes 5070% of total fabric weight

• Finish: Glossy / Matte / Embossed / Lacquered (optional)

3. Physical Properties

• Total Weight: 350950 gsm

• Width: 1.0 3.2 meters (customizable)

• Color: As per Pantone or custom color options

• Adhesion Strength: > 100 N/5cm

• Temperature Resistance: -30C to +70C

• UV Resistance: Optional UV stabilizer, >500 hours (ASTM G154)

• Fire Retardant: Optional (BS 7837, NFPA 701, DIN 4102 B1, etc.)

• Waterproofness: 1000 mm hydrostatic head (ISO 811)

• Mildew Resistance: Yes (treated)

4. Optional Features

• Anti-wicking treatment

• Acrylic / PVDF / PU lacquer finish for extra UV and dirt resistance

• Printable surface (for digital/screen printing)

• REACH / RoHS compliance
